Generator Hybrid Converter with Water Gate Motor Control and Static Transfer Switch for Water Conservancy Projects

This advanced multi-functional converter is equipped with an intelligent Energy Management System (EMS) and offers multiple configurable operating modes, including off-grid, grid-tied, and grid charging. It features a dual LCD smart touchscreen display and incorporates generator power curve tracking technology for optimized performance. The system ensures reliable operation with AC/DC dual backup for auxiliary power supply and includes control technology for handling unbalanced loads. Communication is facilitated through a standard RS485 Modbus RTU protocol. Additionally, a range of optional features are available to enhance functionality, such as PWM dump load overvoltage and overspeed protection, water gate motor control, WIFI/LAN remote monitoring and control via a dedicated app, support for customized sensor control, and the integration of a Static Transfer Switch (STS) for seamless grid-tie/off-grid applications.

Product Details

Product Introduction

GREEF ENERGY multi-functional converter integrates the capabilities of AC-to-DC rectification for PM generators, battery charging, DC-to-AC inversion, and an energy management system. Featuring a configurable dual LCD touchscreen, it utilizes advanced converter technology to achieve stable voltage/frequency control for PMSGs, ensuring seamless Load power supply. It can also be configured to switch to a grid-tied mode for operation and grid charging.

Product Features

🔋 EMS smart energy management system

🔄 Multiple configurable operating modes: off-grid, grid-tied, and grid charging

📱 Double LCD smart touch Screen Display

📈 Generator power curve tracking technology

⚡ AC/DC dual backup for auxiliary power supply

⚖️ Control Technology for Unbalanced Loads

🔌 Stardard RS 485 modbus RTU protocal

🛡️ PMW dump load over voltage over speed protection function (optional)

🚰 Water gate motor control function (optional)

🌐 WIFI/ LAN Remote monitoring and control app available (optional)

🎛️ Support customized sensor control function (optional)

🔀 Support add Static Transfer Switch (STS) for Grid-Tie/Off-Grid Applications (optional)

Product Parameters

Model	Mars-100kt
Rated power(kW)	100
Rated voltage(Vac)	≥ 320
Optimal generator rated voltage(Vac)	450
AC votlage working range(Vac)	240 ~ 550

Maximum AC current(A)	180
Battery type	Lithium-ion
Battery voltage range(Vdc)	350 - 450
Rated battery voltage(Vdc)	400
Max charging&discharging Current(A)	250

Rated charging/discharging power(kw)	100
Rated charge and discharge current(A)	144
Rated grid voltage(V)	400
Permissible grid voltage range(v)	300 - 460
Maximum efficiency(%)	95
